P r o d u c t s - wall speakers - HD-W100
V I D E O
S P E C I F I C A T I O N
Drivers:

1” Soft dome tweeter

6-1/2” poly-coated cone woofer

Crossover: second order

SPL: 88 dB
Frequency Response: 65 - 20,000Hz

Power handing: 30 - 100 watts max

Independence: 8 ohms

Dimensions: 10” x 11-3/4” x 6”D
I N T R O D U C T I O N
The HD-W100 adds solid built quality and performance that is not normally found in a speaker this size.  Now you can have the best of both worlds, a slim speaker  design that can e easily mounted on the wall.  This speaker is great for those who are looking for a monitor that integrate into any small room or wall without filling the decor.
The HD-W100 speaker is crafted out of 3/4" thick MDF (medium density fiberboard) for reduce resonates sound.  The cabinet is vented for enhance bass response.  Each cabinet is aligned with a 1-1/8" soft dome tweeter for smooth warm highs and is accompanied by a massive 6 1/2" aluminum cone woofer driver with a rubber surround, that is now shielded.  The monitor can be placed near a CRT monitor or TV screen without magnetic interference.
The Linkwitz-Riley crossover provides a prefect blending between the woofer and tweeter.  The crossover features quality components like aircore inductors, metallized polypropylene capacitors and low resistant wiring, all joint together by point to point soldering. All the features you will find in our more expensive speakers.
Great all around wall speaker with
clean sound and smooth bass response
G A L L E R Y
P D F   M A N U A L S
High-End
Wall Mountable Sound
Robust Wall Speaker with
Clean Sound

and Smooth Bass Response
Copyright © 2017 MODVO All rights reserved
Innovation Comes From Within
Sound Test
See what inspired us to design
Professional speakers for the home
A quick sound test to check the
sound potential of our speakers
Professional Beyond the home
Quick Guide
Brochure
Ÿ
Wall mountable
Ÿ
Used as wall or desktop
Ÿ
Solid built quality
HD-W100  ON-WALL SPEAKER
Ÿ
Vented cabinet design
Key Features:
Who is it for:
Great for those who want a high performance wall speaker,
that can be mounted on the wall.  Great for small to medium
Size rooms that have limited space.  powered amplifiers rating
from 80- 100 watts per channel.
