S P E C I F I C A T I O N
Drivers:
3/4” Soft dome tweeter
5 1/4” poly-coated paper cone woofer
Crossover: second order
SPL: 88 dB
3/4” Soft dome tweeter
5 1/4” poly-
Crossover: second order
SPL: 88 dB
Frequency Response: 96 - 22,000Hz
Power handing: 19 - 100 watts max
Independence: 8 ohms
Dimensions: 7” x 10” x 7”D
Power handing: 19 -
Independence: 8 ohms
Dimensions: 7” x 10” x 7”D
I N T R O D U C T I O N
The CM-100 adds quality and performance that is not normally found in a speaker this size. It adds clear sound and wide sound stage without the bulk of conventional loudspeakers. Now you can have the best of both worlds, a compact speaker with wide sound stage. This speaker is great for those who are looking for a compact monitor that can easily integrate with a subwoofer or be used in a small where space is limited.
The CM-100 speaker is crafted out of 3/4" thick MDF (medium density fiberboard) for reduce resonates sound. The cabinet is sealed accurate bass response. Each cabinet is aligned with a 3/4” soft dome tweeter for smooth and clear dialogue playback and is accompanied by a 5-1/4" woofer driver with a large rubber surround for deep bass response. The monitor can be placed near a CRT monitor or TV screen without magnetic interference.
The Linkwitz-Riley crossover provides a steep slope and prefect blending between the woofer and tweeter. The crossover features high quality aircore inductors and metallized polypropylene capacitors, all joint together by point to point soldering. All the features you would expect to find in larger and more expensive speaker.
Great all around monitor with clean
sound and smooth bass response
sound and smooth bass response
G A L L E R Y
Simple Design, Sophisticated Sound
|
|
Good sound in tight places
|
|
|
Solid built quality and design
|
|
|
Easily integrate with subwoofer
|
The CM-100 adds good sound and
solid built quality in a compact
A form factor that can be placed in tight
spaces. Surprisingly big open sound at
a very affordable price.
solid built quality in a compact
A form factor that can be placed in tight
spaces. Surprisingly big open sound at
a very affordable price.
